APC Back-UPS CS 500VA
- Item #
- APW BK500
- Mfr. part #
- BK500
- UPC
- 731304016304
$145.00
Protect computers, wireless routers, IOT devices, and security systems with the APC Back-UPS BK 500VA. APC Back-UPS provide backup battery power during power outages and continuously safeguard devices from fluctuating power conditions and surges. With 6 outlets, this tower UPS (uninterruptible power supply) provides seamless battery power to connected electronics. The 300w capacity is ideal for workstations, keeping you connected and productive during power fluctuations. This computer backup offers lifetime guaranteed surge protection with a $100,000 equipment protection policy. Use the included PowerChute software to configure settings and set up automatic graceful shutdown of a connected PC in the event of an extended power outage. Audible alarms provide notification of changing utility power and UPS conditions. Audible alarms can be muted. Package Contains UPS, CD with software, Cord management straps, USB cable, User manual
- Uses your PC to access additional power protection and management features
- Battery notification warns when battery is not able to provide backup power
- Cold-start capability provides temporary power when utility power is out
- Dataline surge protection guards equipment from power surges on data lines
- Wiring fault indicator informs you of potential wiring problems in circuit
General Information
| Manufacturer | Schneider Electric SA |
|---|---|
| Manufacturer Part Number | BK500 |
| Brand Name | APC |
| Product Line | Back-UPS |
| Product Series | CS |
| Product Name | BK500 120V Backup System |
| Packaged Quantity | 1 Each |
| Product Type | Standby UPS |
Technical Information
| Plug/Connector Type | NEMA 5-15P |
|---|---|
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail |
|
| Number of Battery & Surge Outlets | 6 |
| Dataline Protection | RJ-11 |
| Cord Length | 6 ft |
| Phase | Single Phase |
Power Description
| Load Capacity (VA) | 500 VA |
|---|---|
| Load Capacity (Watt) | 300 W |
| Input Voltage | 120 V |
| Input Current | 10 A |
| Output Voltage | 120 V AC |
| Waveform Type | Stepped Approximated Sine Wave |
| Surge Energy Rating | 480 J |
Management
| Alarm |
|
|---|
Controls/Indicators
| Status Indicators | LED status display with On Line, On Battery, Replace Battery, Site wiring fault and Overload Indicators |
|---|
Interfaces/Ports
| Serial Port | Yes |
|---|---|
| USB | Yes |
Battery Information
| Battery Characteristics | Spill-proof, Maintenance-free |
|---|---|
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 15 Minute |
| Typical Battery Recharge Time | 8 Hour |
Environmental Conditions
| Maximum Operating Temperature | 113°F (45°C) |
|---|---|
| Sound Emission (A-Weighted) | 45 dB(A) |
| Thermal Dissipation | 7.03 W |
Physical Characteristics
| Product Color | Beige |
|---|---|
| Height | 6.50" |
| Width | 3.58" |
| Depth | 11.18" |
| Form Factor | Tower |
| Weight (Approximate) | 13.82 lb |
Miscellaneous
| Package Contents | <li>BK500 120V Backup System</li><li>CD with software</li><li>Cord management straps</li><li>USB cable</li><li>User manual</li> |
|---|---|
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Single-use Plastic (SUP) Free Shipping Packaging | No |
Warranty
| Limited Warranty | 3 Year |
|---|---|
| Additional Warranty Information | UPS: 36 month(s)|Battery: 12 month(s) |
