Tripp Lite
Tripp Lite UPS 550VA 300W Desktop Battery Back Up Compact 120V USB RJ11 PC 50/60Hz
- Item #
- TRP INTERNET550U
- Mfr. part #
- INTERNET550U
- UPC
- 013297552138
Account pricing
This item is priced per account. Email or call and we'll send your price.
UPS offers standby protection for PCs and peripherals to prevent data loss and system downtime by providing battery-supported AC output during brownouts and blackouts. Two of the 8 output receptacles are widely spaced to accommodate large transformer plugs. Four outlets with full battery support and surge suppression protect computers, monitors and other vital system components from loss of power. Four additional outlets with surge suppression-only are ideal for printers and other accessories not requiring battery support. Single-line, telephone suppression jacks protect modem or other peripherals with a standard dialup or DSL phone line connection. HID-compliant USB interface enables integration with built-in power management and auto-shutdown features of Windows and Mac OS X. Audible alarm and front panel LEDs offer status information regarding line and battery power operation. 550VA/300 watt power handling ability supports entry-level PCs for up to 17 minutes during power failures.
More from the Manufacturer
- Standby compact UPS protects PCs and peripherals from blackouts, brownouts and surges
- USB communication ports work with free, PowerAlert software for unattended automatic shutdown
- 550VA/300W power capacity; 8 outlets + tel/DSL; 10-minute, 1/2-load runtime
- 99% line-mode efficiency saves energy and operating costs
- $100k Ultimate Lifetime Insurance; 3-year warranty
General Information
| Manufacturer |
Eaton Corporation |
| Manufacturer Part Number |
INTERNET550U |
| Brand Name |
Tripp Lite series |
| Product Line |
Internet Office |
| Product Model |
INTERNET550U |
| Product Name |
Internet Office INTERNET550U 550VA UPS |
| Packaged Quantity |
1 Each |
| Product Type |
Standby UPS |
Technical Information
| Plug/Connector Type |
NEMA 5-15P |
| Receptacle Type |
NEMA 5-15R |
| Receptacle Detail |
10 x NEMA 5-15R |
| Number of Battery & Surge Outlets |
5 |
| Number of Surge-only Outlets |
5 |
| Dataline Protection |
|
| Cord Length |
5 ft |
| Transfer Time |
6 ms |
| EMI/RFI Noise Filter |
Yes |
| Phase |
Single Phase |
| Energy Saving |
Greater than 95% efficiency - GREEN UPS |
| Application/Usage |
- Home/Office
- Media Center
- Commercial
- Computer
- Router
- Printer
- Storage Device
- TV
- Blu-ray Player
- Gaming Console
- Media Player
- DVR
- Audio System
|
Power Description
| Load Capacity (VA) |
550 VA |
| Load Capacity (Watt) |
300 W |
| Input Voltage |
120 V AC |
| Input Current |
12 A |
| Output Voltage |
- 110 V AC
- 115 V AC
- 120 V AC
|
| Output Frequency |
60 Hz |
| Waveform Type |
Pure Sine Wave |
| Surge Energy Rating |
316 J |
Management
| Alarm |
- Low Battery
- Fault
- Overload
- Replace Battery
|
Controls/Indicators
| Status Indicators |
1 x Status LED reports operating mode and fault status |
Interfaces/Ports
| USB (HID Compliant) Port |
Yes |
Battery Information
| DC System Voltage |
12 V DC |
| Backup/Run Time (Full Load) |
1.20 Minute |
| Backup/Run Time (Half Load) |
5 Minute |
| Typical Battery Recharge Time |
6.50 Hour |
| Replaceable Battery |
Yes |
Environmental Conditions
| Maximum Operating Elevation |
10000 ft |
| Storage Temperature |
5°F (-15°C) - 113°F (45°C) |
Physical Characteristics
| Height |
4.13" |
| Width |
4.33" |
| Depth |
7.28" |
| Form Factor |
Ultra-compact Desktop/Tower/Wall Mount |
| Weight (Approximate) |
3.97 lb |
Miscellaneous
| Package Contents |
- Internet Office INTERNET550U 550VA UPS
- USB cable
- Owner's Manual
|
| Software Included |
PowerAlert Software |
| Country of Origin |
China |
| Environmental Compliance |
Restriction of Hazardous Substances (RoHS) |
Warranty
| Limited Warranty |
3 Year |
| Additional Warranty Information |
2 year warranty. $100,000connected equipment insurance (USA, Puerto Rico & Canada Only). |
